LABPOX LV 3D UV | Ultra Low Viscosity Epoxy for Advanced Metallic Floors

LABPOX LV 3D UV is a premium, 100% solids, 2 to 1 specialty epoxy system engineered specifically for high end metallic flooring where maximum movement, depth, and creative control are required. With an ultra low viscosity and an industry leading 90 to 100 minute working time, this system allows installers to manipulate metallic epoxy far longer than standard epoxies.

Built on high performance cycloaliphatic polyamine technology, this resin is designed to produce a superior aesthetic finish with incredible clarity. It is the preferred choice for barber shops, hair and nail salons, custom home garages and automotive retail facilities where a glass like three dimensional effect is the primary goal.

This is a specialty metallic epoxy designed for installers who want full control over their design and refuse to be limited by short working times or thick, restrictive resins.

Where This Product Fits in Your System

• Advanced 3D Metallic Floors: The ultimate body coat for deep, moving metallic effects.
• Large Scale Decorative Projects: Ideal for big pours where you need extra time to maintain a wet edge.
• High Clarity Clear Coats: Can be used as a thick, clear decorative layer over artwork or logos.
• Office and Retail Spaces: Provides a high density surface that prevents dirt penetration for easy maintenance.

Key Features and Benefits

• Ultra Low Viscosity (300 cps): One of the thinnest metallic resins available, allowing pigments to travel further and blend more naturally.
• 90 to 100 Minute Working Time: Nearly double the working time of standard epoxies for effortless 3D floor creations.
• Superior UV Resistance: Engineered for the best possible color stability in its category.
• No Amine Blush: Cures to a clean, high gloss finish without the oily film common in cheaper resins.
• Excellent Defoaming: Formulated to release air naturally, even when applied at heavy 50 mil thicknesses.
• High Resistance to Contamination: Specifically designed to resist fisheyes and surface defects.

Mixing Instructions

Because of the extended pot life, proper mixing is vital to ensure the cycloaliphatic resins activate fully.

• Pre Mix Part A: Mechanically mix Part A for 1 minute before combining to ensure all resins are homogeneous.
• Mix Ratio: Combine 2 parts Part A with 1 part Part B in the larger bucket.
• Mix Time: Mix for a minimum of 3 minutes using a low speed drill (300 to 450 RPM).
• Technique: Scrape the sides and bottom of the container thoroughly. For best results, use a box or cage mixer.
• Immediate Placement: Even with a long working time, the material should be poured onto the floor in ribbons immediately after mixing to prevent heat build up in the pail.

Pro Note: To achieve the ultimate glass like finish and maximum scratch resistance, we recommend pairing this system with Premera T2 once the epoxy has reached its recoat window.

Application Guidelines

To achieve the signature depth of a 3D floor, LABPOX LV 3D UV must be applied at a high build to allow the low viscosity resin to flow and carry the pigments.

• Design Depth: Apply at a maximum 50 square feet per gallon. This provides a thickness of roughly 30 to 32 mils, allowing pigments to sink and swirl for maximum visual impact.
• Technique: Use a squeegee to spread the material, followed by an 18 Inch Magic Trowel to manipulate the metallic design.
• Ideal Conditions: Best results are achieved when the floor and air temperature are between 60°F and 85°F. Avoid high humidity (above 85%) during the application.

⚠️ ENVIRONMENTAL WARNING: Do not apply in direct sunlight or on sunbaked surfaces. Ensure all HVAC vents are directed away from the floor and turn off all fans. Moving air will cause the epoxy to skin over prematurely, which ruins the self leveling and stops the metallic movement.

Coverage and Cure Schedule

• Working Time: 90 to 100 Minutes
• Tack Free: 14 Hours
• Recoat Window: 14 to 24 Hours
• Light Foot Traffic: 48 Hours
• Full Cure: 7 Days

Frequently Asked Questions

What makes the 3D UV version different from standard metallic epoxy?
It features ultra low viscosity (300 cps) and a 90 to 100 minute working time. This allows the resin to flow more like water, which gives the metallic pigments total freedom to move and create deep visual effects.

Does this product resist yellowing?
Yes. LABPOX LV 3D UV is formulated with cycloaliphatic polyamine technology, providing some of the best UV resistance in the epoxy category.

Why is low viscosity important for metallic floors?
Thick epoxies "trap" pigments in place. A low viscosity resin allows the metallic particles to swirl and sink, creating a three dimensional look rather than a flat, painted appearance.

Can I use this for a clear topcoat?
Yes. Its high clarity and excellent defoaming make it an ideal choice for a clear build coat over decorative designs or logos.

How long do I have to wait before walking on the floor?
Because of the extended working time and ultra low viscosity, this system takes longer to reach initial hardness than standard epoxies. You should wait at least 48 hours for light foot traffic. For heavy furniture or vehicle traffic, wait a full 72 hours to ensure the resin has reached its full chemical resistance and hardness.

Can I mix multiple metallic colors together?
Yes. One of the greatest advantages of the ultra low viscosity in LABPOX LV 3D UV is how beautifully it allows different metallic pigments to blend. You can "ribbon" different colors into each other or mist the surface with a secondary color to create natural veining and marble effects that stay fluid longer.

Do I need a specific base coat color for metallic epoxy?
Yes. Metallic pigments are translucent. To achieve the best results, you should apply a solid color epoxy base coat (like LABPOX 35) first. Black is the most common choice as it makes the metallic colors pop with maximum depth, but lighter base colors can be used to create softer, more subtle finishes.

How do I prevent bubbles or "pinholes" in my metallic finish?
Because metallic epoxy is applied at a high build, any air escaping from the concrete (outgassing) will be trapped. You must ensure the slab is perfectly sealed with a primer or moisture barrier like MVB FAST before applying your metallic body coat. This ensures the 3D layer stays smooth and glass like.

What is the best way to create "cells" or "craters" in the design?
If you are looking for specific effects like cells or hammered metal textures, you can lightly mist the surface with 99 percent Isopropyl Alcohol while the epoxy is still in its 90 minute working window. The alcohol breaks the surface tension and causes the metallic pigments to disperse into unique, circular patterns.

Can I apply this over a previous coating?
Yes, but only if the existing coating is well bonded and has been mechanically sanded to a completely dull finish. If there is any gloss remaining, the new metallic layer will not bond properly. Always perform a small test area to ensure compatibility between different resin systems.

What happens if the material starts to heat up in the bucket?
This is known as an exotherm reaction. If the mixed material sits in the pail too long, it will begin to smoke or harden rapidly. If you feel the bucket getting hot, STOP RIGHT THERE! It's ruined. You've left it in the bucket too long and you'll create all kinds of cleanup challenges if you dump that on the floor.
